Antenna arm with tube attachment, [for mast, turret, railing].
Made of iron and zinc-coated antioxidant protection bath.
For fastening in tubes from 35 to 50 mm. (50mm zinc-plated abarcones included)
Dimensions: 560x260 mm.
[Arm tube 25 mm]
Machined aluminum ring to put on tube or 30mm mast. To hold it with Dynemma cable or rope, MASTRANT, etc..Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
Wall/wall claw bracket for mast or tube, composed of zinc-plated iron and galvanized iron sheet for masts up to 60 mm in diameter.
Length: 300 mm.
Profile: 40x20x3 mm.
Plate: 120x200 mm.
Plate Holes: 15mm (x4)
For round tube from 40 to 60 mm.(60mm zinc-plated abarcon included)
Mast bucket, composed of zinc-plated iron rod and galvanized iron sheet for masts up to 45 mm in diameter.
Ideal for joining two masts or a tube make an extension.
Metric rod 6mm
Dimensions: 50x125 mm.
Mast diameter from 20 to 45 mm.
Rope MASTRANT R3 (PRICE PER METRO)
Material: Polyester 3mm Section.Manufacture: Braided with crooked soul with polyester center.Exterior: Cover: Polyester [Sun and Water Resistant in Interperie].
Features: 200 daN force, 60daN safe working load, Elongation 2.4%, weight: 890 gg (in every 100 m).
Mastrant P3 Resistant Rope (PRICE PER METER)Material: 3mm Polyester Section.Manufacture: Braided with twisted core with polyester center.Exterior: Cover: Polyester [Sun and water resistant in Interperie].Features: 200 daN strength, safe work load 60 daN, elongation 2.4%, weight: 0.5 kg (per 100 m).
Round Tube Diameter 25x1000 mm. with a 2mm section for manufacturing different assemblies.
Cutting tolerance +/- 3 mm.
Length: 1000 mm. (1 meter)
Outer Diameter: 25 mm.
Inner Diameter: 21 mm.
Wall: 2 mm.
