There are 74 products.
Robust base for and be able to hold a round tube or mast with the base of 35/40mm Aluminium base 400x400x15mm Mast clamping by machined part with two Metric 8 pins attached to the base with 4 M6 stainless screws.
Robust base for and be able to hold a round tube or mast with the base of 45/50mm Aluminium base 400x400x15mm Mast clamping by machined part with two Metric 8 pins attached to the base with 4 M6 stainless screws.
Robust base for and be able to hold a round tube or mast with the base of 55/60mm Aluminium base 400x400x15mm Mast clamping by machined part with two Metric 8 pins attached to the base with 4 M6 stainless screws. Height of the machined part where the tube enters: 150 mm.External diameter of the round piece: 80mm.Internal Diameter: 60mm.
Robust base to step on with the car wheel and be able to hold a round tube or mast with the base of 45/50mm Aluminium base 200x400x15mm Mast clamping by machined part with two Metric 8 pins attached to the base with 4 M6 stainless screws.
Robust base to step on with the car wheel and be able to hold a round tube or mast with the base of 55/60mm Aluminium base 200x400x15mm Mast clamping by machined part with two Metric 8 pins attached to the base with 4 M6 stainless screws.
MBCL260 Tensioner Technical detailsMetricImperialRope diameter 2 - 5mm 5/64 - 3/16 " Material Black Nylon Nylon Black Hole centers N / Amm N / A " Length 31mm 1 1/4 " Width 10mm 3/8 " Height 18mm 11/16 " Screw size N / A N / A Screw size N / A N / A Weight 22gms 0.1 oz
MBCL276 Tensioner Technical detailsMetricImperialRope diameter 3 - 6mm 5/32 - 5/16 " Material Black Nylon Nylon Black Hole centers N / Amm N / A " Length 68mm 2 5/8 " Width 23mm 7/8 " Height 48mm 1 7/8 " Screw size N / A N / A Screw size N / A N / A Weight 28gms 0.98 oz
MBCL271 Tensioner Technical detailsMetricImperialRope diameter 4 - 8mm 5/32 - 5/16 " Material Black Nylon Nylon Black Hole centers N / Amm N / A " Length 68mm 2 5/8 " Width 23mm 7/8 " Height 48mm 1 7/8 " Screw size N / A N / A Screw size N / A N / A Weight 28gms 0.98 oz
Bracket Cap plate 60mm-40mm. Aluminum holder with outer diameter 60mm and inner diameter 40mm total length 100mm 4 M6x20 Stainless steel screws included for perpendicular attachment to the mast 2 M8x20 captive screws to secure the 40mm tube. Used for Antenna mounts such as Hexbeam, SpiderBeam, Cowebb and similar mounts.
Wall/wall claw bracket for mast or tube, consisting of zinc-plated iron rod and galvanized iron sheet for masts up to 60 mm in diameter. Length: 200 mm. Profile: 40x20x3 mm. Plate: 90x120 mm. Plate Holes: 9mm (x4) For round tube from 40 to 60 mm.(60mm zinc-plated abarcon included)
Wall/wall claw bracket for mast or tube, consisting of zinc-plated iron rod and galvanized iron sheet for masts up to 60 mm in diameter. Length: 600 mm. Profile: 40x20x3 mm. Plate: 120x200 mm. Plate Holes: 15mm (x4) For round tube from 40 to 60 mm. (60mm zinc-plated abarcon included)
Mast bucket, composed of zinc-plated iron rod and galvanized iron sheet for masts up to 45 mm in diameter. Ideal for joining two masts or a tube make an extension. Includes counter-abarcones. Metric rod 6mm Thread: 52mm Dimensions: (De fuera de la varilla a fuera) Largo 140 mm.Ancho 58 mm. Mast diameter from 20 to 45 mm.
Mast bucket, composed of zinc-plated iron rod and galvanized iron sheet for masts up to 50 mm in diameter. Ideal for joining two masts or a tube make an extension. Metric rod 8mm Thread: 52mm Dimensions: (De fuera de la varilla a fuera) Largo 160 mm.Ancho 65 mm. Mast diameter: 25 to 50 mm.
Double antenna arm with tube attachment, [for mast, turret, railing]. Made of iron and zinc-coated antioxidant protection bath. For fastening in tubes from 35 to 50 mm.(50mm zinc-plated abarcones included) Dimensions: 1120x260 mm. [Arm tube 25 mm]
Datos técnicos PolarizaciónVerticalAplicaciónPara mástiles hasta 40 mmDimensiones350x1.030x350 mmFijaciónCon abrazadera para mástilDimensiones del tubo35x1,5 mmBañoProtección antioxidante
Hembrite [Hoop] in Metric Stainless Steel 6 by 40mm in length, ideal for hanging dipoles from arms or supports. [Does not include nuts or washers].
Mast crossover 3 support points, to be able to arrive with wind wire (steel), Dyneema or rope. Diameter 30-55 mm (Galvanized). It is recommended to put cape guard.
EYE ring with Metric 8 thread, in stainless steel (AISI 304).Color: Silver
Machined aluminum ring for 25mm tube or mast. To hold it with Dynemma cable or rope, MASTRANT, etc.. Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
Machined aluminum ring to put on tube or 30mm mast. To hold it with Dynemma cable or rope, MASTRANT, etc.. Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
Machined aluminum ring for 35mm tube or mast. To hold it with Dynemma cable or rope, MASTRANT, etc..Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
![Mast ring (winds) 35mm. [L]](https://mastil-boom.es/2135-home_default/ring-for-mast-winds-35mm-light.jpg)
Machined aluminum ring for 35mm tube or mast. To hold it with Dynemma cable or rope, MASTRANT, etc.. Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
Machined aluminum ring for 40mm tube or mast. To hold it with Dynemma cable or rope, MASTRANT, etc.. Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
Machined aluminum ring to put on tube or 50mm mast. To hold it with Dynemma cable or rope, MASTRANT, etc.. Recommended for portable and fixed installations, ideal as a complement to our telescopic masts.
Machined ring to put on mast or 35mm diameter tube. Recommended for portable installs, ideal as a complement to our telescopic masts. Galvanized plate.
![Clamp 20mm. [MB20]](https://mastil-boom.es/4354-home_default/clamp-20mm-mb20.jpg)
![Clamp 25mm. [MB24]](https://mastil-boom.es/4356-home_default/clamp-25mm-mb24.jpg)
![Clamp 30mm. [MB30]](https://mastil-boom.es/4362-home_default/clamp-30mm-mb30.jpg)
![Clamp 35mm. [MB36]](https://mastil-boom.es/4361-home_default/clamp-35mm-mb36.jpg)
![Clamp 40mm. [MB39]](https://mastil-boom.es/4360-home_default/clamp-40mm-mb39.jpg)
![Clamp 45mm. [MB45]](https://mastil-boom.es/4352-home_default/clamp-45mm-mb45.jpg)
![Clamp 50mm. [MB49]](https://mastil-boom.es/4359-home_default/clamp-50mm-mb49.jpg)
![Clamp 55mm. [MB53]](https://mastil-boom.es/4358-home_default/clamp-55mm-mb53.jpg)
![Clamp 60mm. [MB61]](https://mastil-boom.es/4357-home_default/clamp-60mm-mb61.jpg)
